Flap Wheel Ceramic Oxide

Description

For aggressive grinding with maximum stock removal rate on hard materials which do not conduct heat well. Consistently high performance due to self-sharpening ceramic oxide grain.

Active grinding additives in the coating substantially improve the stock removal rate, prevent clogging and result in cooler grinding.

Depth: 20mm, 30mm, 40mm, 50mm, 60mm

Thickness: 10mm, 15mm, 20mm, 30mm

Grits: 40, 60, 80, 120

Shank dia: 6mm

Materials that can be worked:

• Aluminium
• Cobalt-based alloys
• Other non-ferrous metals
• High-temperature-resistant materials
• Nickel-based alloys (e. g. Inconell and Hasteloy)
• Bronze
• Hard non-ferrous metal
• Titanium
• Copper
• Soft non-ferrous metal
• Brass
• Stainless steel (INOX)
• Grey/nodular cast iron (GG/GJL, GGG/GJS)
• Annealed cast iron
• Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)
• Steel materials with a hardness over 54 HRC
• Steel, cast steel
• Steels up to 1,200 N/mm² (< 38 HRC)

Applications:

• Levelling
• Deburring
• Surface work
• Weld dressing
• Structuring (matt finishing, brush matting and satin finishing)
• Fine grinding in multiple steps

Drive types:

• Flexible shaft drive
• Straight grinder
